GP8700 (Brass)
The Model GP 8700 is a single stage high pressure
regulator that is designed to operate on high pressure
cylinders up to 7500 PSIG. The Model GP 8700 is
suitable for:
- High pressure testing
- Charging accumulators
- Pressurizing aircraft struts
FEATURES
- 0-1500, 2500, 3000, 4500 and 6000 PSIG delivery pressures available
- One piece encapsulated valve design with PCTFE seats and an internal filter
- Ergonomic knob for improved grip
- 1/4” NPT outlet with stainless steel 1/4” tube fitting
- 2 1/2” dual scale gauges (psi/bar)
- Conforms to CGA E-4 standard for gas pressure regulators
* Models with the following CGA inlet connections are self venting – 346, 347, 580, 590, 677, 680
For full details on the product, download the PDF below
GP8700 |
|||||
Part no. | Model no. | Gas | Max Inlet PSIG | Delivery Pressure Range PSIG | Delivery Pressure Gauge PSIG |
3200310 | 8700 1500 346 | Medical Air | 3000 | 0 1500 | 3000 |
3200311 | 8700 2500 346 | 3000 | 0 2500 | 3000 | |
3200312 | 8700 1500 347 | 5500 | 0 1500 | 3000 | |
3200314 | 8700 3000 347 | 5500 | 0 3000 | 4000 | |
3200315 | 8700 4500 347 | 5500 | 0 4500 | 6000 | |
3200302 | 8700 1500 350 | Hydrogen, Methane | 3000 | 0 1500 | 3000 |
3200303 | 8700 2500 350 | 3000 | 0 2500 | 4000 | |
3200316 | 8700 1500 695 | 5500 | 0 1500 | 3000 | |
3200318 | 8700 3000 695 | 5500 | 0 3000 | 4000 | |
3200319 | 8700 4500 695 | 5500 | 0 4500 | 6000 | |
3200304 | 8700 1500 590 | Industrial Air | 3000 | 0 1500 | 3000 |
3200305 | 8700 2500 590 | 3000 | 0 2500 | 4000 | |
3200306 | 8700 1500 540 | Oxygen | 3000 | 0 1500 | 3000 |
3200307 | 8700 2500 540 | 3000 | 0 2500 | 4000 | |
3200308 | 8700 1500 540 Surge Guard | 3000 | 0 1500 | 3000 | |
3200309 | 8700 2500 540 Surge Guard | 3000 | 0 2500 | 4000 | |
3200300 | 8700 1500 580 | Nitrogen, Argon, Helium | 3000 | 0 1500 | 3000 |
3200301 | 8700 2500 580 | 3000 | 0 2500 | 4000 | |
3200320 | 8700 1500 677 | 7500 | 0 1500 | 3000 | |
3200321 | 8700 3000 677 | 7500 | 0 3000 | 4000 | |
3200322 | 8700 4500 677 | 7500 | 0 4500 | 6000 | |
3200323 | 8700 6000 677 | 7500 | 0 6000 | 10000 | |
3200324 | 8700 1500 680 | 5500 | 0 1500 | 3000 | |
3200326 | 8700 3000 680 | 5500 | 0 3000 | 4000 | |
3200327 | 8700 4500 680 | 5500 | 0 4500 | 6000 |
