7 Bar Twin Polyamide Filter Housing 1/4
Materials Polyamide
Pressure 7 Bar
Ports 1/4”
Element 12.32. & 12.57.
NT series twin filter housings have two elements and bowls fitted to a single head. The first stage is a pre-filter or coalescing element and the second stage a particulate element. They are constructed entirely from polyamide and the bowls use a clear polyamide. They are supplied with 1/4" ports and have a range of drain options. There are two mounting holes in the back face of the head for neat installation. Standard housings have a Viton seal. Other seal types are available as an option. BSPT and BSPP port types are also available.
Twin Polyamide Filter Housing | ||||
Port Size | Drain 1st Stage | Drain 2nd Stage | Max | |
Ordering Information | NPT | NPT | NPT | W/P |
Inch | Inch | Inch | Bar | |
NT1111-2601 | 1/4 | Manual | None | 7 |
NT1111-2101 | 1/4 | 1/8 | None | 7 |
NT1211-2601 | 1/4 | Manual | None | 7 |
NT1211-2101 | 1/4 | 1/8 | None | 7 |
NT1221-2601 | 1/4 | Manual | None | 7 |
NT1221-2101 | 1/4 | 1/8 | None | 7 |
