Absorber Housing – NN212.AD & NN232.AD

Materials Polyamide Pressure 10 Bar Ports 1/4” or 1/2”

Technical Specifications Housing Model Port Size Drain Maximum Pressure, Bar Maximum Temperature, oC Materials of Construction Head, Bowl & Internals Seals Filter Pads Principal Dimensions in mm Diameter Height Volume, cc Weight, kg Accessories Mounting Bracket CF/2.1/054 NN212.201.AD 1/4" NPT None 10 50 PA Viton PE 65 147 125 0.2 MBSS21 NN212.401.AD 1/2" NPT None 10 50 PA Viton PE 65 147 125 0.2 MBSS21 NN232.201.AD 1/4" NPT None 10 50 PA Viton PE 65 246 250 0.25 MBSS21 NN232.401.AD 1/2" NPT None 10 50 PA Viton PE 65 246 250 0.25 MBSS21 The NN212 & NN232 Adsorber Housings are a simple, cost effective solution for the adsorption of various chemical vapours in a gaseous stream. The hollow tube, with integral filter diverts the gas flow to the base of the bowl allowing complete passage of gas through the adsorber granules. Simply remove the filter bowl without disturbing the line connections to replace the used adsorber media. It is recommended to use a coalescing filter housing as a pre-filter to remove liquid aerosols and droplets. Housings are available with 1/4" or 1/2" ports and have NPT ports and Viton seals. Other seal types are available as an option. BSPT and BSPP port types are also available. A range of granular adsorber materials are available and these are listed below. together with the principle uses. We are pleased to advise about any special applications you may have. The media is supplied in resealable plastic containers and two sizes are available, 1 litre or 4 litres.
